Bevel gear
Bevel gears are primarily used to transmit power between two non-parallel or intersecting axes. Their tooth shape is umbrella-like, and the gear takes the form of a cone, allowing them to operate at different axes. The main types of bevel gears include straight bevel gears, spiral bevel gears, and conical gears.
Features of Bevel Gears
Bevel gears change the direction of rotation of the input shaft through the meshing of two bevel gears. When one bevel gear rotates, its inclined tooth shape causes the other bevel gear to rotate as well, thereby transferring motion from one shaft to another.
Change of Direction
Bevel gears can effectively change the direction of power input, which is one of their primary uses.
Transmission Efficiency
Bevel gears have relatively high meshing efficiency, especially when properly designed, achieving over 90% operational efficiency.
Load Capacity
With improvements in tooth shape and materials, modern bevel gears can support high loads and provide stable power transmission.
Diverse Design
Bevel gears can be designed according to specific needs, using either straight or spiral teeth, and can be adjusted in size and shape based on the application.
Compactness
The configuration of bevel gears is usually more compact than other types of gear systems, making them suitable for applications with space constraints.
Specific Application Cases
Bevel gears are essential components in mechanical transmission systems.
With their ability to change direction and high efficiency, they play a critical role in various industrial and high-tech applications.
